6mm² XLPE Insulation DC Solar Cable TUV EN50618 Certified for Photovoltaic Systems

Name: 6mm² XLPE Insulation DC Solar Cable TUV EN50618 Certified for Photovoltaic Systems
Brand: ZHEJIANG PNTECH TECHNOLOGY CO., LTD
SKU: H1Z2Z2-K
Availability: InStock

제품 상세정보

인증: TUV & CE & ISO9001 & CQC & CPR & BCA

Model Number: H1Z2Z2-K

지불과 운송 용어

Minimum Order Quantity: 500

가격: 협상 가능

Packaging Details: 100m/roll

Delivery Time: 7-25days

지불 조건: T/T, 보자마자 L/C

Supply Ability: 10000000

최상의 가격을 얻으세요

지금 연락하세요

사양

설명

사양

강조하다:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    6mm² DC Solar Cable, XLPE Insulation Photovoltaic Cable, TUV EN50618 Certified Solar Direct Current Cable


색상:	검은 색/ 빨간색	무게:	760kg/km
케이블 유형:	태양 케이블	단열재:	가교 폴리에틸렌(XLPE)
아니오를 입력하세요:	H1Z2Z2-K 1x6mm2	Rohs 준수:	예
케이블 유형:	광전지(PV) 케이블	포장:	롤 당 200m

색상:	검은 색/ 빨간색
무게:	760kg/km
케이블 유형:	태양 케이블
단열재:	가교 폴리에틸렌(XLPE)
아니오를 입력하세요:	H1Z2Z2-K 1x6mm2
Rohs 준수:	예
케이블 유형:	광전지(PV) 케이블
포장:	롤 당 200m

설명

6mm² XLPE Insulation DC Solar Cable TUV EN50618 Certified for Photovoltaic Systems

Product Overview

The DC Solar Cable is an advanced and reliable solution designed specifically for solar energy systems, offering exceptional performance and durability. Manufactured in compliance with the stringent TUV EN50618 standard, this cable ensures safety, efficiency, and long-term reliability in photovoltaic installations.

At the core of this cable's superior performance is its use of Cross-linked Polyethylene (XLPE) as the insulation material. XLPE insulation provides excellent thermal resistance, mechanical strength, and chemical stability, making it perfectly suited for harsh conditions encountered in solar power installations.

Key Features

Product Name: DC Solar Cable
Type No: H1Z2Z2-K 1x6mm²
Sheath Material: XLPE (Cross-linked Polyethylene)
Insulation Material: Cross-linked Polyethylene (XLPE)
Cable Type: Photovoltaic (PV) Cable
Weight: 760 kg/km
Designed for solar energy applications
Ensures efficient DC power transmission
Suitable for outdoor and solar panel connections

Technical Specifications

Parameter	Specification
Insulation Material	Cross-linked Polyethylene (XLPE)
Conductor Size	6mm² (Range: 4mm² to 16mm²)
Conductor Material	Tinned Copper
RoHS Compliant	Yes
Cable Type	Photovoltaic (PV) Cable
Type Number	H1Z2Z2-K 1x6mm²
Cable Outer Diameter (OD)	6.1mm
Sheath	XLPE
Standard	TUV EN50618

Applications

The H1Z2Z2-K DC Solar Cable is designed specifically for solar power systems and is certified by TUV, CE, ISO9001, CQC, CPR, and BCA. This cable guarantees reliability and safety in various solar energy applications including:

Connecting solar panels to inverters, charge controllers, and batteries
Residential, commercial, and industrial solar power systems
Rooftop solar panels and solar farms
Off-grid solar setups

With an excellent temperature range of -40°C to +90°C, the cable is suitable for both extreme cold and hot environments, making it ideal for outdoor solar installations in diverse climatic conditions.

Customization Options

We offer customization services tailored to your needs with the following options:

Minimum order quantity: 500 units
Available in black and red colors
Packaging: 100m or 200m rolls
Weight: 760kg per kilometer
Supply ability: Up to 10,000,000 units
Delivery time: 7 to 25 days
Payment terms: T/T and L/C at sight
Pricing: Negotiable based on order volume

Support & Services

Our DC Solar Cable is designed to provide reliable and efficient performance for solar power installations. We offer comprehensive technical support services including:

Detailed installation guidelines and product manual
Technical support for installation queries and performance optimization
Warranty claims assistance
Expert guidance to maximize lifespan and efficiency

Packing & Shipping

Each DC Solar Cable is carefully packaged to ensure protection during transit. Cables are coiled neatly and secured with durable ties, placed inside sturdy plastic bags to prevent moisture and dust exposure, then packed into reinforced cardboard boxes designed to withstand shipping stresses.

We use reliable carriers with tracking options and offer bulk packaging solutions for large orders to optimize shipping efficiency and reduce costs.

Frequently Asked Questions

Q: What is the model number of this DC Solar Cable?

A: The model number of this DC Solar Cable is H1Z2Z2-K.

Q: Where is the DC Solar Cable manufactured?

A: This DC Solar Cable is made in China.

Q: What certifications does the DC Solar Cable have?

A: The DC Solar Cable is certified with TUV, CE, ISO9001, CQC, CPR, and BCA.

Q: What is the minimum order quantity and packaging details for this cable?

A: The minimum order quantity is 500 units, and the cable is packaged in rolls of 100 meters each.

Q: What are the payment terms and delivery time for the DC Solar Cable?

A: Payment can be made via T/T or L/C at sight. Delivery time ranges from 7 to 25 days depending on the order size.
